Technical data
Torque Range100 Nm...14.000 Nm
Mechanical Rating (n1= 1400 min-1)0, 22...150 kW
Gear ratios5, 4...1715
Output Configuration
Foot and Shaft mount - Two Bore Options per Size
Keyless Shrink Disc Fitting
Metric or Inch series Solid Output shaft
Adapter bushings matching more shaft diameters
Splined hollow shaft
Input Configurations
IEC and NEMA motor Adaptors
Servomotor adapters
Metric or Inch series Solid Input Shaft
Easy to operate handwheel speed control as standard
Optional electric remote speed control
Wide selection of motors and brake-motors
Analog and digital speed indicators available
Rugged cast iron body
Ground and polished driving disc for minimum wear
Special cam mechanism only transmits the required torque, minimizing wear
Asbestos-free non-hygroscopic friction disc material for long and safe working life
Case is opened without special tooling for fast and easy maintenance
1: Helical-bevel gear two-stage reducer
2: Compact str
