* Water-cooling
*According to the size of the load, automatic parallel and dispel
*City electric automatic detection, self-starting, automatic shutdown
*Generating sets automatic faults protection
*Two running one standby or one running one standby
*Reverse power protection
*The automatic synchronization, the automatic accurate same time switches on
*Optional smart communication interface, the realization of remote control, communications
*According to the need to be extended to eight units running in parallel.
Mian features:
1.Preparation of a dual-purpose use of the most arbitrary way into two units running in parallel, as another back-up unit, can be realized with the power or the power unit automatically parallel.
2. Active and idle work load degree of error ≤10% rated powers: When automatic running may realize the automatic synchronization, the accurate same time to switch on, the automatic adjustment of frequency and loading.
3. In automatic operation mode, when the city power failure (over-voltage, under voltage, phase missing), the three units start at the same time, the closing of the first unit put into operation, and the other two units by the automatic shutdown delay; during the operation If the unit load in more than 80% of the rated power, while at the same time opening the other two units. Parallel to switch on the unit into operation, and the other generating units by the automatic shutdown delay, as a back-up units in the unit to run the event of the failure can be automatically opened,and put into operation
; In the running, if the load below the rated power of 40%, the delay out of a self-generating unit, the unit run cooler by automatically shutdown; When electricity returned to normal after delay, the crew at the city gate switching power supply load, and run cooler by the unit after the automatic shutdown..
4. With a high temperature, low oil pressure, over-voltage generators, generators less voltage, over-current short-circuit, over speed, less speed, over frequent, less frequently, such as protection.
5.during the units parallel operation with reverse power protection
*According to the size of the load, automatic parallel and dispel
*City electric automatic detection, self-starting, automatic shutdown
*Generating sets automatic faults protection
*Two running one standby or one running one standby
*Reverse power protection
*The automatic synchronization, the automatic accurate same time switches on
*Optional smart communication interface, the realization of remote control, communications
*According to the need to be extended to eight units running in parallel.
Mian features:
1.Preparation of a dual-purpose use of the most arbitrary way into two units running in parallel, as another back-up unit, can be realized with the power or the power unit automatically parallel.
2. Active and idle work load degree of error ≤10% rated powers: When automatic running may realize the automatic synchronization, the accurate same time to switch on, the automatic adjustment of frequency and loading.
3. In automatic operation mode, when the city power failure (over-voltage, under voltage, phase missing), the three units start at the same time, the closing of the first unit put into operation, and the other two units by the automatic shutdown delay; during the operation If the unit load in more than 80% of the rated power, while at the same time opening the other two units. Parallel to switch on the unit into operation, and the other generating units by the automatic shutdown delay, as a back-up units in the unit to run the event of the failure can be automatically opened,and put into operation
; In the running, if the load below the rated power of 40%, the delay out of a self-generating unit, the unit run cooler by automatically shutdown; When electricity returned to normal after delay, the crew at the city gate switching power supply load, and run cooler by the unit after the automatic shutdown..
4. With a high temperature, low oil pressure, over-voltage generators, generators less voltage, over-current short-circuit, over speed, less speed, over frequent, less frequently, such as protection.
5.during the units parallel operation with reverse power protection
Features
- AUTOMATIC PARALLELING SYS VERSTION
- * Water-cooling
- *According to the size of the load, automatic parallel and dispel
- *City electric automatic detection, self-starting, automatic shutdown
- *Generating sets automatic faults protection
- *Two running one standby or one running one standby
- *Reverse power protection
- *The automatic synchronization, the automatic accurate same time switches on
- *Optional smart communication interface, the realization of remote control, communications.
