Pre-wash device in washing room, the water flows out directly, no glass powder is left.
Rise washing room and get the current required distance (glass thickness). Electric operation
Three water tanks, water heating, each water tank cycles separately, water conserving.
Set maintenance model. (the washing room can open 500mm for easy operation and adjusting air knives)
Four-point rising guide screw achieve fine fitting for helping to adjusting the roller level, but chain disassembling is unnecessary.
The air blower on the machine body, room saving.
Rise washing room and get the current required distance (glass thickness). Electric operation
Three water tanks, water heating, each water tank cycles separately, water conserving.
Set maintenance model. (the washing room can open 500mm for easy operation and adjusting air knives)
Four-point rising guide screw achieve fine fitting for helping to adjusting the roller level, but chain disassembling is unnecessary.
The air blower on the machine body, room saving.
Features
- Technical parameter
- Max. washing size 2200mm
- Min. washing size 400*200mm
- Washing glass thickness 3～40mm
- Transmission power 1.5kW
- Air blower power 18.5 kW
- Brush 3pairs/180mm diameter/0.1mm /wite/premium-grade nylon
- Roller totally encapsulated
- Water tank 3/heating
- Air knives 2pairs
